Schneider Electric XB4BVM3 Selector Switch, 2-Position, Spring Return, 22mm Mounting - XB4BVM3

Introducing the Schneider Electric XB4BVM3 Selector Switch, a reliable and versatile component designed to meet your electrical control needs. This selector switch features a 2-position design with spring return functionality. It's suitable for a wide range of applications and offers easy and convenient use with its 22mm mounting size.

Key Features:

Versatile Selector: The XB4BVM3 offers a 2-position selector, making it ideal for applications requiring toggling between two states.

Spring Return Functionality: This switch is equipped with spring return, ensuring it returns to its original position when released, making it suitable for momentary operations.

22mm Mounting: The 22mm mounting size is a standard in the industry, allowing for compatibility with various control panels and enclosures.

Durable Build: Crafted with high-quality materials, this selector switch is built to withstand demanding environments.

Technical Specifications:

Positions: 2

Operation: Spring Return

Mounting Size: 22mm

Specifications
Main
Range of product	Harmony XB4
Product or component type	Pilot light
Device short name	XB4
bezel material	Chromium plated metal
Fixing collar material	Zamak
Mounting diameter	22 mm
Head type	Standard
Sale per indivisible quantity	1
Shape of signaling unit head	Round
Cap/operator or lens colour	Green
Operator additional information	With plain lens
Light source	Universal LED
Bulb base	Integral LED
light source colour	Green
[Us] rated supply voltage	230...240 V AC 50/60 Hz
Complementary
height	47 mm
Width	30 mm
Depth	54 mm
Terminals description ISO n°1	(X1-X2)PL
Net weight	0.08 kg
Resistance to high pressure washer	7000000 Pa at 55 °C, distance : 0.1 m
Connections - terminals	Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1
	Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to IEC 60947-1
[Ui] rated insulation voltage	250 V (pollution degree 3) conforming to IEC 60947-1
[Uimp] rated impulse withstand voltage	4 kV conforming to IEC 60947-1
Signalling type	Steady
Current consumption	14 mA
Service life	100000 h at rated voltage and 25 °C
Surge withstand	1 kV conforming to IEC 61000-4-5
Device presentation	Complete product
Supply voltage limits	195…264 V AC
Environment
Protective treatment	TH
Ambient air temperature for storage	-40…70 °C
Ambient air temperature for operation	-40…70 °C
Electrical shock protection class	Class I conforming to IEC 60536
IP degree of protection	IP66 conforming to IEC 60529
	IP67
	IP69
	IP69K
NEMA degree of protection	NEMA 13
	NEMA 4X
IK degree of protection	IK06 conforming to IEC 50102
standards	JIS C8201-5-1
	CSA C22.2 No 14
	IEC 60947-5-5
	IEC 60947-5-1
	UL 508
	IEC 60947-5-4
	IEC 60947-1
	JIS C8201-1
product certifications	CSA
	UL listed
Vibration resistance	5 gn (f= 12…500 Hz) conforming to IEC 60068-2-6
Shock resistance	30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
	50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Resistance to fast transients	2 kV conforming to IEC 61000-4-4
Resistance to electromagnetic fields	10 V/m conforming to IEC 61000-4-3
Resistance to electrostatic discharge	6 kV on contact (on metal parts) conforming to IEC 61000-4-2
	8 kV in free air (in insulating parts) conforming to IEC 61000-4-2
Electromagnetic emission	Class B conforming to IEC 55011

Weight	0.080000
Brand	Schneider Electric
Model	XB4BVM3
Depth [cm]	54
Width [cm]	30
Height [cm]	47
Range	Harmony XB4
Family	IDSIG

Selector Switch, 2-Position, Spring Return, 22mm Mounting, Schneider Electric
