Selector Switch, 2-Position, Momentary, Spring Return, 22mm Mounting, Schneider Electric

In stock
SKU
XB4BVM6
Special Price EGP 617 Regular Price EGP 1,065
Quick Overview

Range of product: Harmony XB4
Product type: Pilot light
Type of operator: Plain lens
Shape of signaling unit head: Round

"

Introducing the Schneider Electric XB4BVM6 Selector Switch, a reliable and versatile component designed to meet your electrical control needs. This selector switch features a 2-position design with momentary functionality and spring return. It's suitable for a wide range of applications and offers easy and convenient use with its 22mm mounting size.



Key Features:

Versatile Selector: The XB4BVM6 offers a 2-position selector, making it ideal for applications requiring toggling between two states.

Momentary Functionality: With momentary operation, it's perfect for applications where a temporary electrical connection is needed.

Spring Return: The spring return feature ensures that the switch returns to its default position after activation.

22mm Mounting: The 22mm mounting size is a standard in the industry, allowing for compatibility with various control panels and enclosures.



Technical Specifications:

Positions: 2

Operation: Momentary, Spring Return

Mounting Size: 22mm



Specifications

Main


Range of productHarmony XB4
Product or component typePilot light
Device short nameXB4
bezel materialChromium plated metal
Fixing collar materialZamak
Mounting diameter22 mm
Head typeStandard
Sale per indivisible quantity1
Shape of signaling unit headRound
Cap/operator or lens colourBlue
Operator additional informationWith plain lens
Light sourceUniversal LED
Bulb baseIntegral LED
light source colourBlue
[Us] rated supply voltage230...240 V AC 50/60 Hz
Complementary
height47 mm
Width30 mm
Depth54 mm
Terminals description ISO n°1(X1-X2)PL
Net weight0.08 kg
Resistance to high pressure washer7000000 Pa at 55 °C, distance : 0.1 m
Connections - terminalsScrew clamp terminals, <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1
 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end conforming to IEC 60947-1
[Ui] rated insulation voltage250 V (pollution degree 3) conforming to IEC 60947-1
[Uimp] rated impulse withstand voltage4 kV conforming to IEC 60947-1
Signalling typeSteady
Current consumption14 mA
Service life100000 h at rated voltage and 25 °C
Surge withstand1 kV conforming to IEC 61000-4-5
Device presentationComplete product
Supply voltage limits195…264 V AC
Environment
Protective treatmentTH
Ambient air temperature for storage-40…70 °C
Ambient air temperature for operation-40…70 °C
Electrical shock protection classClass I conforming to IEC 60536
IP degree of protectionIP66 conforming to IEC 60529
 IP67
 IP69
 IP69K
NEMA degree of protectionNEMA 13
 NEMA 4X
IK degree of protectionIK06 conforming to IEC 50102
standardsIEC 60947-5-1
 UL 508
 IEC 60947-1
 IEC 60947-5-4
 IEC 60947-5-5
 JIS C8201-5-1
 CSA C22.2 No 14
 JIS C8201-1
product certificationsUL listed
 CSA
Vibration resistance5 gn (f= 12…500 Hz) conforming to IEC 60068-2-6
Shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Resistance to fast transients2 kV conforming to IEC 61000-4-4
Resistance to electromagnetic fields10 V/m conforming to IEC 61000-4-3
Resistance to electrostatic discharge6 kV on contact (on metal parts) conforming to IEC 61000-4-2
 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2
Electromagnetic emissionClass B conforming to IEC 55011
More Information
BrandSchneider Electric
ModelXB4BVM6
Depth [cm]54
Width [cm]30
Height [cm]47
