Schneider Electric EasyLogic PM2210, Power & Energy meter, Total Harmonic, LCD display, Pulse, class 1
Out of stock
SKU
METSEPM2210
Special Price EGP 20,976 Regular Price EGP 27,599
Quick Overview
Range: EasyLogic
Product type: Power meter
Device application: Sub billing, Power monitoring
Power quality analysis: total harmonic distortion
You May Also Like:
Schneider Electric VarPlus Can HDuty Capacitor, 25/30 kvar, 400 V, 50/60HzSpecial Price EGP 6,509 Regular Price EGP 9,431
Schneider Electric EasyLogic METSEDM1210 Power and Energy Meter, 1-Phase, Class 0.5SSpecial Price EGP 1,131 Regular Price EGP 1,488
Schneider Electric Power Factor controller, VarPlus Logic, VPL 12Special Price EGP 25,654 Regular Price EGP 40,721
Schneider Electric Voltmeter, GoLogic Panel Meter, DM3125, Three PhasesSpecial Price EGP 1,183 Regular Price EGP 1,503
Schneider Electric EasyCan Capacitor, 20/24 kvar, 400 V, 50/60HzSpecial Price EGP 3,079 Regular Price EGP 5,727
Schneider Electric VarPlus Can HDuty Capacitor, 20-24 kVar, 400V, 50-60HzSpecial Price EGP 5,207 Regular Price EGP 7,795
Schneider Electric HDuty Capacitor, 10.4/12.5 kvar, 400 V, 50/60HzSpecial Price EGP 3,142 Regular Price EGP 5,408
Schneider Electric VarPlus Can HDuty Capacitor, 15/18 kvar, 400 V, 50/60HzSpecial Price EGP 4,175 Regular Price EGP 6,379
Schneider Electric VarPlus Can HDuty Capacitor, 30/36 kvar, 400 V, 50/60HzSpecial Price EGP 7,810 Regular Price EGP 10,797
Schneider Electric EasyCan Capacitor, 15/18 kvar, 400 V, 50/60HzSpecial Price EGP 2,298 Regular Price EGP 4,894
Schneider Electric Heavy Duty PowerLogic PFC Capacitor, 22.7/27.2 kvar, 480V, 50/60HzSpecial Price EGP 5,880 Regular Price EGP 6,024
Schneider Electric Heavy Duty PowerLogic PFC Capacitor, 33.9/40.7 kvar, 480 V, 50/60HzSpecial Price EGP 8,798 Regular Price EGP 13,191
Schneider Electric Heavy Duty PowerLogic PFC Capacitor, 8.8/10.6 kvar, 480 V, 50/60HzSpecial Price EGP 2,981 Regular Price EGP 4,930
Schneider Electric VarPlus Can HDuty Capacitor, 40/48 kvar, 400 V, 50/60HzSpecial Price EGP 10,369 Regular Price EGP 13,730
Schneider Electric VarPlus Can HDuty Capacitor, 7.5/9 kvar, 400 V, 50/60HzSpecial Price EGP 2,963 Regular Price EGP 5,188
Schneider Electric Power Factor Controller, VarPlus Logic, VPL 6Special Price EGP 18,214 Regular Price EGP 28,910
This device is a panel mount or flush mount power meter with a 96mm by 96mm bezel size having backlit LCD display of 128 by 128 pixels. The meter measures active energy as per accuracy class Class 1.0 complying to IEC 62053-21 standard with sampling rate of 64 samples per cycle. Able to measures all three vectors of power and energy such as Active, Apparent & Reactive beside Voltages, Current, Frequency and Power Factor. Plus the total Harmonic Distortion for both current and volrage on per phase basis. The meter will function in either 50Hz or 60Hz network frequency and accepts universal control power voltages ranging from 44 to 300 V Line to Neutral AC or DC voltages. Rated current for this meter is either 1A or 5A input. it supports up to 13 different types of wiring schemes under Single Phase, Two Phase or Three Phase configuration types. The range of measurement voltage between Phases is 35 to 480 V Line to Line AC at 45 to 65 Hz while it is 20 to 277 V between Line and Neutral. The meter also has one digital pulse output for any energy parameters congigurable to different energy scaling. Product dimensions are as follows: width 3.78 in (96 mm), depth 2.16 in (54 mm), height 3.78 in (96 mm) and product weight 10.58 oz (300 g).
Specifications:
| Main | |
| Range | EasyLogic |
| product name | EasyLogic PM2200 |
| Product or component type | Power meter |
| Device short name | PM2210 |
| Complementary | |
| Device application | Sub billing |
| Power monitoring | |
| Power quality analysis | total harmonic distortion |
| Type of measurement | Apparent power min/max, total |
| Active and reactive power min/max, total | |
| Current min/max, avg | |
| Voltage min/max, avg | |
| Frequency min/max, avg | |
| Total current harmonic distortion THD (I) per phase | |
| Total voltage harmonic distortion THD (U) per phase | |
| Power factor min/max, avg | |
| Apparent energy total | |
| Active and reactive energy total | |
| Metering type | Voltage U, U21, U32, U13, V, V1, V2, V3 |
| Unbalance current | |
| Calculated neutral current | |
| Apparent power S, S1, S2, S3 | |
| Peak demand currents | |
| Current I, I1, I2, I3 | |
| Active, reactive, apparent energy (signed, four quadrant) | |
| Active power P, P1, P2, P3 | |
| Reactive power Q, Q1, Q2, Q3 | |
| Peak demand power PM, QM, SM | |
| Demand power P, Q, S | |
| Accuracy class | Class 1 active energy conforming to IEC 62053-21 |
| Class 1 reactive energy conforming to IEC 62053-24 | |
| Measurement accuracy | Apparent power +/- 1 % |
| Active energy +/- 1 % | |
| Reactive energy +/- 1 % | |
| Active power +/- 1 % | |
| Voltage +/- 0.5 % | |
| Power factor +/- 0.01 | |
| Current +/- 0.5 % | |
| Frequency +/- 0.05 % | |
| Measurement current | 5…6000 mA |
| Measurement voltage | 35…480 V AC 50/60 Hz between phases |
| 20…277 V AC 50/60 Hz between phase and neutral | |
| 480…999000 V AC 50/60 Hz with external VT | |
| Frequency measurement range | 45…65 Hz |
| [Us] rated supply voltage | 44...277 V AC 45...65 Hz +/- 10 % |
| 44...277 V DC +/- 10 % | |
| Network frequency | 60 Hz |
| 50 Hz | |
| Ride-through time | 100 ms 120 V AC typical |
| 400 ms 230 V AC typical | |
| 50 ms 125 V DC typical | |
| [In] rated current | 1 A |
| 5:00 AM | |
| Maximum power consumption in VA | 6 VA at 277 V AC |
| Maximum power consumption in W | 3.3 W (power lines (AC)) |
| 2 W at 277 V (power lines (DC)) | |
| input impedance | Current (impedance <= 0.3 mOhm) |
| Voltage (impedance > 5 MOhm) | |
| Tamperproof of settings | Protected by access code |
| Display type | Backlit LCD |
| Display colour | Monochrome |
| Display resolution | 128 x 128 pixels |
| Demand intervals | Configurable from 1 to 60 min |
| Information displayed | Demand current (past value) |
| Demand current (present value) | |
| Demand power (past value) | |
| Demand power (present value) | |
| Voltage | |
| Current | |
| Frequency | |
| Energy consumption | |
| Harmonic distortion | |
| Power factor | |
| Active power | |
| Apparent power | |
| Reactive power | |
| Unbalanced in % | |
| Harmonic amplitude | |
| Control type | 4 x button |
| Local signalling | Red LED: output signal 1...9999000 pulse/ k_h (kWh, kVAh, kVARh) |
| Green LED: module operating (RUN) | |
| Number of inputs | 0 |
| Number of outputs | 1 pulse |
| POP parameter | Pulse: 20 ms (5...40 V DC, 20 mA max)1...9999000 pulse/ k_h (kWh, kVAh, kVARh) |
| Impulse duration | 20 ms |
| Communication port protocol | POP |
| Sampling rate | 64 samples/cycle |
| Cybersecurity | Enable/disable communication ports |
| Communication service | Remote monitoring |
| User language | German |
| English | |
| Chinese | |
| Russian | |
| Spanish | |
| Portuguese | |
| French | |
| Product certifications | CE conforming to IEC 61010-1 |
| CULus conforming to UL 61010-1 | |
| CULus conforming to CSA C22.2 No 61010-1 | |
| RCM | |
| EAC | |
| C-Tick | |
| Mounting mode | Clip-on |
| Mounting position | Vertical |
| Mounting support | Framework |
| Provided equipment | 1 x installation guide |
| Measurement category | Category III 480 V |
| Category II 480…600 V | |
| Electrical insulation class | Class II |
| Double insulation | |
| Flame retardance | V-0 conforming to UL 94 |
| Connections - terminals | Current transformer: screw connection (bottom) 6 |
| Voltage inputs: screw connection (top) 4 | |
| Material | Polycarbonate |
| Width | 96 mm |
| Depth | Total : 76.09 mm |
| Embedded : 61.64 mm | |
| Height | 96 mm |
| Net weight | 300 g |
| Compatibility code | PM2210 |
| Environment | |
| Service life | 7 year(s) |
| IP degree of protection | IP54 front: conforming to IEC 60529 |
| IP30 body: conforming to IEC 60529 | |
| Relative humidity | 5…95 % at 50 °C |
| Pollution degree | 2 |
| Ambient air temperature for operation | -10…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Operating altitude | <= 2000 m |
| Electromagnetic compatibility | Electrostatic discharge conforming to IEC 61000-4-2 |
| Radiated radio-frequency electromagnetic field immunity test conforming to IEC 61000-4-3 | |
| Electrical fast transient/burst immunity test conforming to IEC 61000-4-4 | |
| Surge immunity test conforming to IEC 61000-4-5 | |
| Conducted RF disturbances conforming to IEC 61000-4-6 | |
| Magnetic field at power frequency conforming to IEC 61000-4-8 | |
| Voltage dips and interruptions immunity test conforming to IEC 61000-4-11 | |
| Emission tests conforming to FCC part 15 class A | |
| Overvoltage category | III |
| Weight | 1.000000 |
|---|---|
| Brand | Schneider Electric |
| Model | METSEPM2210 |
| Range | EasyLogic |
| Family | DPLVP |
