Schneider Electric VarPlus Can HDuty Capacitor, 20-24 kVar, 400V, 50-60Hz
Product Type: Heavy duty capacitor
Series name: HDuty
IP degree of protection: IP20
Type of installation: Indoor installation
Introducing the Schneider Electric VarPlus Can HDuty Capacitor, a robust and reliable solution for improving power factor and enhancing energy efficiency in your electrical systems. Engineered to ensure the efficient use of electricity, this heavy-duty capacitor is designed for various applications, making it a valuable asset for businesses and industries.
Key Features:
Power Factor Improvement: With a power rating of 20-24 kVar, this capacitor enhances the power factor of your electrical systems, leading to reduced energy costs and optimized performance.
Wide Voltage Compatibility: Designed to operate at 400V and compatible with 50-60Hz electrical systems, it suits a wide range of installations.
Energy Efficiency: Enhance energy efficiency, reduce energy wastage, and minimize losses in your electrical network.
High-Quality Construction: Schneider Electric is renowned for its high-quality electrical components, and this capacitor is no exception.
Reliable Performance: Ensure dependable and consistent performance in maintaining power factor and electrical efficiency.
Technical Specifications:
Rating: 20-24 kVar
Voltage: 400V
Frequency: 50-60Hz
| Specifications | |
Main | |
| Range of product | PowerLogic |
| Product or component type | Heavy duty capacitor |
| Network frequency | 50/60 Hz |
| Series name | HDuty |
| Network harmonic content | <= 20 % |
| Electrical parameters | 18.1 kvar 380 V 50 Hz |
| 21.7 kvar 380 V 60 Hz | |
| 20 kvar 400 V 50 Hz | |
| 24 kvar 400 V 60 Hz | |
| 21.5 kvar 415 V 50 Hz | |
| 25.8 kvar 415 V 60 Hz | |
| Maximum permissible voltage | 1.1 x Un (8 hours over 24 hours) |
| continuous overcurrent capacity | 1.8 x In |
| Rated voltage | 380…415 V AC 50/60 Hz |
| Complementary | |
| dielectric losses | < 0.2 W/kvar |
| Power losses | < 0.5 W/kVAr |
| capacitance tolerance | - 5 % to 10 % |
| Voltage test | 2.15 x Un AC between terminals for 10 s |
| <= 660 V - 3 kV AC between terminal and container for 10 s | |
| >= 660 V - 6 kV AC between terminal and container for 10 s | |
| inrush current | 250 x In |
| Maximum switching operation per year | 7000 |
| Service life in hours | 130000 h |
| Dielectric material | Metallized polypropylene film with Zn/Al alloy, special resistivity & profile, special edge (wave cut) |
| Impregnation material | Non-PCB dry PUR resin |
| Biodegradable | |
| Type of installation | Indoor installation |
| Connections - terminals | ClampTite terminal |
| Mounting mode | Upright/horizontal |
| Diameter | 116 mm |
| height | 242 mm |
| Net weight | 2.5 kg |
| Environment | |
| standards | IEC 60831-1 |
| IEC 60831-2 | |
| IP degree of protection | IP20 |
| Operating altitude | 2000 m |
| Temperature class | D |
| Ambient air temperature for operation | -25…55 °C |
| Weight | 2.500000 |
|---|---|
| Brand | Schneider Electric |
| Model | BLRCH200A240B40 |
| Height [cm] | 24.2 |
| Diameter [cm] | 11.6 |
| Range | PFC |
| Family | DPLVP |
