Schneider Electric EasyCan Capacitor, 15/18 kvar, 400 V, 50/60Hz
In stock
SKU
BLRCS150A180B40
Special Price EGP 3,496 Regular Price EGP 4,661
Schneider Electric EasyCan Capacitor, 15/18 kvar, 400 V, 50/60Hz is available to buy in increments of 1
Quick Overview
Range: EasyLogic
Product type: Standard duty capacitor
Mounting mode: Vertical
Network frequency: 50/60 Hz
You May Also Like:
Schneider Electric EasyLogic METSEDM1210 Power and Energy Meter, 1-Phase, Class 0.5SSpecial Price EGP 1,131 Regular Price EGP 1,488
Schneider Electric EasyLogic METSEDM3110 Power and Energy Meter, 3-Phase, Class 0.5SSpecial Price EGP 1,456 Regular Price EGP 1,915
Schneider Electric EasyLogic PM2220 Power and Energy Meter, Up to 15th H, LCD, RS485, Class 1Special Price EGP 13,247 Regular Price EGP 17,431
Schneider Electric EasyLogic METSEDM3210 Power and Energy Meter, 3-Phase, Class 0.5SSpecial Price EGP 1,370 Regular Price EGP 1,803
Schneider Electric EasyLogic PM2210, Power & Energy meter, Total Harmonic, LCD display, Pulse, class 1Special Price EGP 20,976 Regular Price EGP 27,599
Schneider Electric, EASYLOGIC VAF P AND E RS485 31STHAR CL 0 (METSEPM2130)Special Price EGP 12,234 Regular Price EGP 16,097
Schneider Electric EasyCan Capacitor, 20/24 kvar, 400 V, 50/60HzSpecial Price EGP 4,091 Regular Price EGP 5,454
Schneider Electric EasyCan Capacitor, 12.5/15 kvar, 400 V, 50/60HzSpecial Price EGP 3,302 Regular Price EGP 4,402
Schneider Electric Varlogic PF Controller RT12 Step 440VSpecial Price EGP 16,920 Regular Price EGP 22,561
EasyCan capacitor are designed to work in slightly polluted netwroks with Detuned reactors. These capacitors are used for standard operating conditions,and when no significant non-linear loads are present. These capacitor are the right choice to maximize the savings in an electrical system which is stable. This capacitor provides a rated output power of 13.5 kVar at 380V AC,50 Hz. Fastening assured by a ClampTite terminal. This component meet the standards IEC 60831-1 and IEC 60831-2. The case product weight is 1.3 kg.
Specifications:
| Main | |
| Range | EasyLogic |
| Product or component type | Standard duty capacitor |
| product name | EasyLogic PFC Capacitor |
| Network frequency | 50/60 Hz |
| Series name | EasyLogic PFC Capacitor |
| Network harmonic content | <= 10 % |
| Electrical parameters | 13.5 kvar 380 V 50 Hz |
| 16.2 kvar 380 V 60 Hz | |
| 15 kvar 400 V 50 Hz | |
| 18 kvar 400 V 60 Hz | |
| 16.1 kvar 415 V 50 Hz | |
| 19.4 kvar 415 V 60 Hz | |
| Maximum permissible voltage | 1.1 x Un (8 hours over 24 hours) |
| continuous overcurrent capacity | 1.5 x In |
| Rated voltage | 380…415 V AC 50/60 Hz |
| Complementary | |
| Dielectric losses | < 0.2 W/kvar |
| Power losses | < 0.5 W/kVAr |
| Capacitance tolerance | - 5 % to 10 % |
| Voltage test | 2.15 x Un AC between terminals for 10 s |
| <= 660 V - 3 kV AC between terminal and container for 10 s | |
| >= 660 V - 6 kV AC between terminal and container for 10 s | |
| Inrush current | 200 x In |
| Maximum switching operation per year | 5000 |
| Service life in hours | 100000 h |
| Dielectric material | Metallized polypropylene film with Zn/Al alloy, |
| Impregnation material | Non-PCB soft PUR resin |
| Biodegradable | |
| Type of installation | Indoor installation |
| Connections - terminals | ClampTite terminal |
| Mounting mode | Vertical |
| Diameter | 75 mm |
| Height | 308 mm |
| Net weight | 1.3 kg |
| Environment | |
| Standards | IEC 60831-1 |
| IEC 60831-2 | |
| IP degree of protection | IP20 |
| Operating altitude | 2000 m |
| Temperature class | D |
| Ambient air temperature for operation | -25…55 °C |
| Relative humidity | 95% |
| Weight | 3.000000 |
|---|---|
| Brand | Schneider Electric |
| Model | BLRCS150A180B40 |
| Range | EasyLogic |
| Family | DPLVP |
| Type | Standard duty capacitor |
| Voltage ~ Frequency | 50-60 Hz |
| IP Degree of Protection | IP20 |
