Schneider Electric Varlogic PF Controller RT12 Step 440V
Range: EasyLogic
Product type: Power factor controller
Operating mode: Manual
Display type: 7 Segments LED, 4-digit
You May Also Like:
Schneider Electric EasyLogic METSEDM1210 Power and Energy Meter, 1-Phase, Class 0.5SSpecial Price EGP 1,131 Regular Price EGP 1,488
Schneider Electric EasyLogic METSEDM3110 Power and Energy Meter, 3-Phase, Class 0.5SSpecial Price EGP 1,456 Regular Price EGP 1,915
Schneider Electric EasyLogic PM2220 Power and Energy Meter, Up to 15th H, LCD, RS485, Class 1Special Price EGP 13,247 Regular Price EGP 17,431
Schneider Electric EasyLogic METSEDM3210 Power and Energy Meter, 3-Phase, Class 0.5SSpecial Price EGP 1,370 Regular Price EGP 1,803
Schneider Electric EasyLogic PM2210, Power & Energy meter, Total Harmonic, LCD display, Pulse, class 1Special Price EGP 20,976 Regular Price EGP 27,599
Schneider Electric, EASYLOGIC VAF P AND E RS485 31STHAR CL 0 (METSEPM2130)Special Price EGP 12,234 Regular Price EGP 16,097
Schneider Electric EasyCan Capacitor, 15/18 kvar, 400 V, 50/60HzSpecial Price EGP 3,496 Regular Price EGP 4,661
The Varlogic controllers permanently monitor the reactive power of the installation. This device also control the connection and disconnection of capacitor steps in order to obtain the targeted power factor. In case of overvoltage, low power factor or over compensation an alarm relay will activate. The user can parameter the power factor from 0.85 induct to 1. New control algorithm designed to reduce the number of switching operations and quickly attain the targeted power factor. This version include 12 step output contacts for a range of compensations. Output contacts are calibrated for 3 amps load at 250 V or 1 amp load at 400 V. The power supply allow voltage input from 320 to 460 V The dimensions of the controller are 143 mm in width, 143 mm in height, 67 mm in depth for a product weight of 800 g. Cerified for Electromagnetic Compatibility with IEC 61326, IEC 61000-6-2 and IEC 61000-6-4. A 139 mm by 139 mm swithcboard cut-out will be necessary for the flush panel mounting.
Specifications:
| Main | |
| Range | EasyLogic |
| product name | EasyLogic PFC Controller |
| Device short name | RT12 |
| Product or component type | Power factor controller |
| Complementary | |
| Number of step output contacts | ١٢ |
| [Us] rated supply voltage | 320...460 V AC 50/60 Hz |
| Measurement current | 50 mA |
| Operating mode | Manual |
| Display type | 7 segments LED |
| 4-digit | |
| Type of measurement | Power factor |
| Alarm function | 5 last alarms |
| Input type | Phase to phase |
| Current input CT...10000/5 A | |
| Output type | Free outputs contacts current: 0.3 A 110 V DC |
| Free outputs contacts current: 0.6 A 60 V DC | |
| Free outputs contacts current: 1 A 400 V AC 50/60 Hz | |
| Free outputs contacts current: 2 A 24 V DC | |
| Free outputs contacts current: 2 A 250 V AC 50/60 Hz | |
| Free outputs contacts current: 5 A 120 V AC 50/60 Hz | |
| Type of setting | Target cos phi: 0.85 inductive...1 |
| Measurement accuracy | +/- 2 % |
| Time delay range | 10...1800 s |
| 10...1800 s (on reconnection) | |
| Step sequences | 1.1.2.4 |
| 1.2.2.2 | |
| 1.2.4.8 | |
| 1.1.2.2 | |
| 1.1.2.3 | |
| 1.2.3.3 | |
| 1.2.3.4 | |
| 1.2.4.4 | |
| 1.1.1.1 | |
| Linear | |
| 1.2.3.6 | |
| Mounting location | In cabinet |
| Panel | |
| Height | 143 mm |
| Width | 143 mm |
| Depth | 67 mm |
| Net weight | 0.8 kg |
| Environment | |
| Standards | EN 61010-1 |
| IEC 61326 | |
| IEC 61000-6-2 | |
| IEC 61000-6-4 | |
| IP degree of protection | Rear face: IP20 |
| Front face: IP41 conforming to IEC 60429 | |
| ambient air temperature for operation | 0…55 °C |
| Weight | 3.000000 |
|---|---|
| Brand | Schneider Electric |
| Model | 51213 |
| Range | EasyLogic |
| Family | DPLVP |
| IP Degree of Protection | IP20 |
