Schneider Electric Miniature Circuit Breaker, C60H, 2 Poles, 20 A, C Curve
Out of stock
SKU
A9N61532
Special Price EGP 1,964 Regular Price EGP 2,999
Quick Overview
Range: Acti9
Product type: Miniature circuit-breaker
Device application: Distribution
Poles description: 2P
You May Also Like:
Schneider Electric Overvoltage release, Acti9, iMSU, voltage release, 230 V ACSpecial Price EGP 999 Regular Price EGP 6,326
Schneider Electric Acti9 iC60N, 63 A Miniature Circuit Breaker, 2P, C curveSpecial Price EGP 951 Regular Price EGP 1,464
Schneider Electric Acti9 iC60N Miniature circuit-breaker, 2P, 10 A, C curveSpecial Price EGP 750 Regular Price EGP 1,145
Schneider Electric Acti9 IIL Single Indicator Light, White, 110-230 VACSpecial Price EGP 336 Regular Price EGP 525
Schneider Electric iCT contactor, 25A 1NO 230...240V 50HzSpecial Price EGP 1,389 Regular Price EGP 2,170
Schneider Electric Acti9 iC60H Miniature Circuit Breaker (MCB), 1 Pole, 50A, C Curve, 10000A,15KSpecial Price EGP 918 Regular Price EGP 1,412
Schneider Electric Miniature Circuit Breaker (MCB), Acti9 IC60H, 3P, 6A, C-Curve,15KSpecial Price EGP 2,583 Regular Price EGP 3,974
Schneider Electric Acti9 iC60H Miniature circuit-breaker, 3P, 50 A, C curve,15KSpecial Price EGP 3,347 Regular Price EGP 5,109
Schneider Electric Miniature Circuit-Breaker, Acti9 IC60N, 2P, 25 A, C Curve, 6000 ASpecial Price EGP 750 Regular Price EGP 1,145
Schneider Electric Acti9 IDPN N Vigi RCBO , 1P + N, 20A, C Curve, 6000A, 30mA, Type ASpecial Price EGP 3,357 Regular Price EGP 4,632
Schneider Electric Acti9 iC60N, 40 A Miniature Circuit Breaker, 2P, C curveSpecial Price EGP 744 Regular Price EGP 1,145
Schneider Electric Miniature Circuit-Breaker, Acti9 iC60N, 4P, 63 A, C Curve, 6000 ASpecial Price EGP 2,486 Regular Price EGP 3,796
Schneider Electric Miniature Circuit Breaker (MCB), Acti9 iC60N, 2P, 10A, C curveSpecial Price EGP 436 Regular Price EGP 586
Schneider Electric Miniature Circuit-Breaker, Acti9 Ic60H, 1P, 63 A, C Curve, 10000 A, 15KSpecial Price EGP 810 Regular Price EGP 1,236
Schneider Electric Miniature Circuit Breaker (MCB) , Acti9 IC60N , 1P , 6A , D Curve , 6000A IEC/EN 60898, 1, 10kA IEC/EN 60947, 2Special Price EGP 448 Regular Price EGP 689
Schneider Electric Acti9 iC60N, 32A Miniature Circuit Breaker, 2P, C curveSpecial Price EGP 745 Regular Price EGP 1,145
Schneider Electric Acti9 iC60H Miniature Circuit Breaker (MCB), 4P 32A, D Curve, 10,000A, IEC/EN 60898-1, 15kA IEC/EN 60947-2Special Price EGP 3,030 Regular Price EGP 4,661
Schneider Electric Acti9 iC60N 10 A Miniature Circuit Breaker 4P, C curveSpecial Price EGP 1,886 Regular Price EGP 2,902
Schneider Electric Acti9 IIL Single Indicator Light, Blue, 110, 230 VACSpecial Price EGP 443 Regular Price EGP 692
This Acti9 C60H-DC is a low voltage direct current miniature circuit breaker (MCB). It has 2P, rated current 20A and C tripping curve. The rated short circuit breaking capacity goes up to 20kA at 220VDC conforming to GB 14048.2 standard and 20kA at 220VDC conforming to GB 14048.2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker combines functions of circuit protection against short circuit and overload current, control and isolation. It offers VisiTrip for safety during maintenance and VisiSafe to reduce intervention time. The Acti9 C60H-DC is used in direct current circuit (industrial control and automation, transport, renewable energy). This device is dedicated to industrial control, automations, transport and renewable energy applications.
Main | |
| Range | Acti9 |
| product name | Acti9 C60H-DC |
| Product or component type | Miniature circuit-breaker |
| Device short name | C60H-DC |
| Device application | Distribution |
| Poles description | 2P |
| Number of protected poles | ٢ |
| [In] rated current | 20 A at 25 °C |
| Network type | DC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 10 kA Icu at 440 V DC conforming to EN 60947-2 |
| 10 kA Icu at 440 V DC conforming to IEC 60947-2 | |
| 6 kA Icu at 500 V DC conforming to EN 60947-2 | |
| 6 kA Icu at 500 V DC conforming to IEC 60947-2 | |
| 20 kA Icu at 220 V DC conforming to GB 14048.2 | |
| 20 kA Icu at 220 V DC conforming to IEC 60947-2 | |
| 20 kA Icu at 250 V DC conforming to GB 14048.2 | |
| 20 kA Icu at 250 V DC conforming to IEC 60947-2 | |
| Utilisation category | Category A conforming to EN 60947-2 |
| Category A conforming to IEC 60947-2 | |
| Suitability for isolation | Yes conforming to IEC 60947-2 |
| Yes conforming to EN 60947-2 | |
| Standards | EN 60947-2 |
| IEC 60947-2 | |
| Complementary | |
| Network frequency | 50/60 Hz |
| [Ue] rated operational voltage | 500 V DC |
| [Ics] rated service breaking capacity | 15 kA 75 % conforming to EN 60947-2 - 220 V DC |
| 15 kA 75 % conforming to IEC 60947-2 - 220 V DC | |
| 15 kA 75 % conforming to EN 60947-2 - 250 V DC | |
| 15 kA 75 % conforming to IEC 60947-2 - 250 V DC | |
| 4.5 kA 75 % conforming to EN 60947-2 - 500 V DC | |
| 4.5 kA 75 % conforming to IEC 60947-2 - 500 V DC | |
| 7.5 kA 75 % conforming to EN 60947-2 - 440 V DC | |
| 7.5 kA 75 % conforming to IEC 60947-2 - 440 V DC | |
| [Ui] rated insulation voltage | 500 V DC conforming to IEC 60947-2 |
| 500 V DC conforming to EN 60947-2 | |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to EN 60947-2 |
| 6 kV conforming to IEC 60947-2 | |
| Contact position indicator | Yes |
| Control type | Toggle |
| Local signalling | ON/OFF indication |
| Mounting mode | Fixed |
| Mounting support | 35 mm symmetrical DIN rail |
| Comb busbar and distribution block compatibility | Top or bottom: standard |
| 9 mm pitches | 4 |
| Net weight | 0.256 kg |
| Colour | White |
| Mechanical durability | 20000 cycles |
| Electrical durability | 3000 cycles L/R = 2 ms |
| Provision for padlocking | Padlockable |
| Locking options description | In position O |
| Tightening torque | Power circuit: 2.5 N.m top or bottom |
| Earth-leakage protection | Without |
| Environment | |
| Pollution degree | 3 conforming to EN 60947-2 |
| 3 conforming to IEC 60947-2 | |
| Overvoltage category | IV |
Tropicalisation2 conforming to IEC 60068-2Operating altitude2000 mAmbient air temperature for operation-25…70 °CAmbient air temperature for storage-40…85 °C
| Weight | 3.000000 |
|---|---|
| Brand | Schneider Electric |
| Model | A9N61532 |
| Color | White |
| Device Application | Distribution |
| Range | Acti9 |
| Family | HDCFD |
| Type | Miniature circuit-breaker |
| Poles | 2P |
| [In] Rated Current | 20 A at 25 °C |
| Voltage ~ Frequency | 50-60 Hz |
