Schneider Electric 1000VA Easy UPS 1 Ph On-Line, Tower, 230V, Intelligent Card Slot, LCD
Capacity: 1000VA / 800W
Transfer time: 0 ms
Power Factor: 0.8 : 1
Output connection type: 3 IEC 60320 C13
The SRVS1KI is your reliable power protection solution. It's an APC Smart-UPS SRV 1000VA that provides premium backup power and scalable runtime for servers, storage, and networks. Whether you need to safeguard critical data or keep your business operations running smoothly during power disturbances, this UPS has you covered.
Key Features:
High-Performance UPS: The SRVS1KI delivers double-conversion online power protection with zero transfer time, ensuring seamless power to your critical devices.
1000VA Capacity: With 1000VA/900W capacity, it can support multiple servers, storage systems, and networking equipment.
Scalable Runtime: You can extend runtime by adding optional external battery packs to meet your specific runtime requirements.
Intuitive LCD Display: The bright and easy-to-read LCD screen provides real-time UPS status updates, making it simple to monitor power conditions.
SmartSlot Compatibility: This UPS includes a SmartSlot for adding network management cards to remotely monitor and manage your UPS.
Protect Your Critical Equipment: The SRVS1KI Smart-UPS offers high-performance protection for servers, networking devices, and storage systems.
Scalable Runtime: Easily expand your backup runtime to ensure your systems stay operational during extended power outages.
Remote Management: Add network management cards to the SmartSlot for remote monitoring and control of your UPS.
Ensure the continuous operation of your critical equipment with the SRVS1KI Smart-UPS from APC. Invest in reliable power protection today.
Smart-UPS On-Line Applications
Data Networks
- Business Critical Servers
- Mid-Range Servers (Windows and Linux)
- Wi-Fi Applications
- Data Network Backbones
- Data Storage
Medical Devices/ Labs
- Control of Imaging Systems
- Enable safe shutdown
- Blood Bank Equipment
- Pharmacies/ Cold Chain Solutions
- Facilities Equipment
- Environmental Control Systems
Voice Networks
- Cellular Sites
- Voice over IP (VOIP)
- Very Small Aperture Terminals (VSAT) PBX
- IT Enabled PBX
Industrial
- Programmable Logic Controllers (PLC)
- Industrial Robots
- Controls for Windmills
| Specifications | |
Overview | |
| Presentation | For small to medium businesses, Easy UPS 1 Ph On-Line provides essential power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments. |
| Main | |
Run time for load | 3min 49s |
| Main Input Voltage | 230 V |
| Product or component type | Uninterruptible power supply (UPS) |
| Other Input Voltage | 220 V |
| 240 V | |
| Main Output Voltage | 230 V |
| Other Output Voltage | 220 V |
| 240 V | |
| Rated power in W | 800 W |
| Rated power in VA | 1000 VA |
| Input Connection Type | IEC 60320 C14 |
| output connection type | 3 IEC 60320 C13 |
| Cable length | 1.50 m |
| Provided equipment | 1 IEC 60320 C13 to Schuko power cable |
| 1 USB cable | |
| 1 RS-232 configuration cable | |
| 1 user manual | |
| Batteries & Runtime | |
| Battery type | Lead-acid battery |
| Battery voltage | 24 V |
| Number of battery filled slots | 1 |
| Number of battery free slots | 0 |
| Battery recharge time | 4 h |
| Battery life | 3…5 year(s) |
| Battery charger power | 30 W rated |
| General | |
| Max runtime | 4 min |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Redundant | No |
| Physical | |
| Colour | Black (RAL 7010) |
| height | 22.3 cm |
| Width | 14.5 cm |
| Depth | 28.8 cm |
| Mounting location | Front |
| mounting support | Floor |
| Mounting preference | No preference |
| Mounting mode | Not rack-mountable |
| USB compatible | Yes |
| Mounting position | Vertical |
| Input | |
| Input voltage limits | 110...285 V half load |
| 160...280 V full load | |
| Network frequency | 40...70 Hz auto sensing |
| Output | |
| Maximum configurable power in VA | 1000 VA |
| Maximum configurable power in W | 800 W |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| UPS type | Double conversion online |
| Wave type | Sine wave |
| Efficiency | 88 % (full load) |
| Additional information | Configurable for 220 : 230 or 240 nominal output voltage |
| bypass type | Internal bypass (automatic and manual) |
| Crest factor | 3:01 |
| Conformance | |
| product certifications | CE |
| UKCA | |
| Standards | EN/IEC 62040-1:2019/A11:2021 |
| EN/IEC 62040-2:2006/AC:2006 | |
| EN/IEC 62040-2:2018 | |
| Environmental | |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity | 0…95 % non-condensing |
| Operating altitude | 0...3000 m |
| Ambient air temperature for storage | -20…50 °C |
| Storage Relative Humidity | 0…95 % non-condensing |
| Storage altitude | 0…15000 m |
| Acoustic level | 50 dBA |
| Heat dissipation | 372 Btu/h |
| IP degree of protection | IP20 |
| Communications & Management | |
| Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Free slots | 1 |
| control panel | Multifunction LCD status and control console |
| Surge Protection and Filtering | |
| Surge energy rate | 600 J |
| Weight | 9.300000 |
|---|---|
| Brand | Schneider Electric |
| Model | SRVS1KI |
| Color | Black |
| Depth [cm] | 28.8 |
| Width [cm] | 14.5 |
| Height [cm] | 22.3 |
| Range | SRVS |
| Rated Power in VA | 1000 VA |
| Rated Power In W | 800 Watt |
| Power Factor | 0.8 |
| Transfer Time | 0 MS |
| Input Voltage | 230 V |
| Output Voltage | 230 V |
