Schneider Electric TeSys F, Contactor Coil, LX1FH, 24 V AC 40...400 Hz
Schneider Electric TeSys F, Contactor Coil, LX1FH, 24 V AC 40...400 Hz is available to buy in increments of 1
Quick Overview
Range: TeSys
Product type: Contactor coil
Product compatibility: LC1F265, LC1F330
Control circuit type: AC at 40...400 Hz
TeSys F AC coil 24V 40-400Hz (voltage code B7),low sealed consumption,for TeSys F 3-pole and 4-pole contactors LC1 F265,F330. It operates in voltage limits 0.85-1.1 Uc and environments until 55°C. It provides high operating rates to the contactor,until 2400 cycles/hour. Green Premium compliant (RoHS/REACh)
Specifications:
| Main | |
| Range | TeSys |
| Product or component type | Contactor coil |
| Device short name | LX1FH |
| Range compatibility | TeSys TeSys F LC1F contactor |
| Product compatibility | LC1F265 |
| LC1F330 | |
| Control circuit type | AC at 40...400 Hz |
| [Uc] control circuit voltage | 24 V AC 40...400 Hz |
| Average resistance | 0.8 Ohm inrush at 20 °C |
| 20 Ohm holding at 20 °C | |
| Operating time | 100...170 ms opening |
| 40...65 ms closing | |
| Mechanical durability | 10 Mcycles |
| Maximum operating rate | 2400 cyc/h 55 °C |
| Complementary | |
| Coil technology | Without built-in suppressor module |
| Control circuit voltage limits | Drop-out: 0.35...0.55 Uc 40...400 Hz (at 55 °C) |
| Operational: 0.85...1.1 Uc 40...400 Hz (at 55 °C) | |
| Inrush power in VA | 650 VA 40...400 Hz cos phi 0.9 (at 20 °C) |
| Hold-in power consumption in VA | 10 VA 40...400 Hz cos phi 0.3 (at 20 °C) |
| Heat dissipation | 8 W at 40...400 Hz |
| Environment | |
| ambient air temperature for operation | -5…55 °C |
| Net weight | 0.75 kg |
| Weight | 3.000000 |
|---|---|
| Brand | Schneider Electric |
| Model | LX1FH0242 |
| Range | TeSys F |
| Family | PPCTR |
