Schneider Electric New Unica Socket outlet, with Shutter, 2 Modules, Anthracite
Range: New Unica
Product or component type: USB charger
Device presentation: Mechanism
Condition of use: Indoor
Schneider Electric New Unica socket-outlet NU308454 is a in color anthracite. Its matching mounting box can be recessed into the surface of the wall with flush type. New Unica includes a suite of new designs, colors and materials. Users benefit from beautiful design that match their style and innovative products. New Unica is designed with clever features to be flexible, easy to understand and quick to install providing solutions for all customers requirements.
Specifications:
Main | |
Range | New Unica |
product or component type | Socket-outlet |
Device presentation | Mechanism |
Device mounting | Flush |
Socket number | 1 |
Outlet poles configuration | 2P + E |
Outlet standard description | Pin earth |
Rated current | 13 A |
Complementary | |
Device application | Power supply |
Cover type | With shutter |
[Ue] rated operational voltage | 250 V |
Network type | AC |
Network frequency | 50/60 Hz |
Number of modules | 2 modules |
Fixing mode | Clip-in |
Colour tint | Anthracite (RAL 7021) |
Connections - terminals | Screw terminals |
Cable cross section | 0…4 mm² - cable stiffness: flexible |
0…4 mm² - cable stiffness: rigid | |
Minimum load breaking capacity | 100 operations 1.25 In and 1.1 Un, cos phi = 0.6 |
Electrical durability | 10000 cycles, cos phi = 0.8 |
Insulation resistance | > 5 MOhm at 500 V |
Dielectric strength | 2000 V |
Material | PC: mechanism cover |
PC (polycarbonate) GF10 FR: casing | |
Surface finish | Painted |
Quantity per set | Set of 1 flow-pack |
Standards | IEC 60884-1 |
Embedding depth | 32 mm |
Depth | 43 mm |
Width | 45 mm |
Height | 45 mm |
net weight | 0.035 kg |
Surface treatment | Painted |
Resistance to chemical agents | Resistant to alcohol (70 %) |
Resistant to alcohol (96 %) | |
Resistant to A-Lactic Acid | |
Resistant to diluted quaternary ammonium | |
Resistant to diluted bleach | |
Resistant to diluted ammonia | |
Resistant to soapy water | |
Resistant to crystal cleaner | |
Resistant to hydrogen peroxide 10 volumes | |
Resistant to hexane | |
Environment | |
ambient air temperature for operation | -5…35 °C |
ambient air temperature for storage | -5…50 °C |
IK degree of protection | IK01 |
IP degree of protection | IP20 |
Environmental characteristic | Acetone |
Bleach | |
UV resistant | |
Petrol | |
Oil | |
Alcohol | |
Window-cleaning fluid | |
Liquid soap |
| Brand | Schneider Electric |
|---|---|
| Model | NU308454 |
| Color | Anthracite |
| Range | Unica |
| Family | HDCWD |
| Type | Socket-Outlet |
| Number of Modules | 2 modules |
| Fixing Mode | Clip-in |
| IP Degree of Protection | IP20 |
| IK Degree of Protection | IK01 |
