Schneider Electric Control Relay, TeSys K, 4P (4NO), <=690V, 220...230V AC coil
In stock
SKU
CA2KN40M7
Special Price EGP 1,391 Regular Price EGP 2,575
Schneider Electric Control Relay, TeSys K, 4P (4NO), <=690V, 220...230V AC coil is available to buy in increments of 1
Quick Overview
Range: TeSys
Product type: Control relay
Contactor application: Control Circuit
Pole contact composition: 4 NO
You May Also Like:
Schneider Electric TeSys D contactor, 3P (3 NO) - AC-3 - <= 440 V 12 A - 42 V AC coilSpecial Price EGP 1,548 Regular Price EGP 2,867
Schneider Electric TeSys D Contactor, 3P, 3NO, AC3 440V, 18A, 220V AC CoilSpecial Price EGP 1,938 Regular Price EGP 3,590
Schneider Electric Contactor, Tesys D, 3P, Normally Open, 440V AC,3, 40A, 220V AC, 50,60Hz CoilSpecial Price EGP 4,591 Regular Price EGP 8,502
Schneider Electric Tesys D Contactor, 3P, 3NO, AC3 440V, 12A, 220V AC CoilSpecial Price EGP 1,548 Regular Price EGP 2,867
Schneider Electric Tesys D Control Relay, 5 NO, 690V, 220V AC Standard CoilSpecial Price EGP 1,371 Regular Price EGP 2,538
Schneider Electric TeSys D contactor, 3P (3 NO) - AC-3 - <= 440 V 115 A - 42 V AC 50/60 Hz coilSpecial Price EGP 15,802 Regular Price EGP 29,264
Schneider Electric TeSys LRD Thermal Overload Relay, 2.5,4 A, Class 10ASpecial Price EGP 2,024 Regular Price EGP 3,748
Schneider Electric Tesys D Contactor, 3P, 3NO, AC3 440V, 65A, 220V AC 50/60Hz CoilSpecial Price EGP 7,418 Regular Price EGP 13,737
Schneider Electric Tesys D Contactor, 3P, 3NO, AC3 440V, 9A, 220V AC CoilSpecial Price EGP 1,404 Regular Price EGP 2,601
Schneider Electric Contactor Mechanical Latch Contact BlockSpecial Price EGP 4,384 Regular Price EGP 8,118
Schneider Electric Tesys, D Contactor Coil, 220V AC, 50, 60Hz, for 9, 38A ContactorSpecial Price EGP 622 Regular Price EGP 1,151
Schneider Electric Tesys D Contactor, 3P, 3 NO, AC3 440V, 9A, 24V AC CoilSpecial Price EGP 1,404 Regular Price EGP 2,601
Schneider Electric Thermal Overload Relay, 12-18 A, Class 10ASpecial Price EGP 2,443 Regular Price EGP 4,524
Schneider Electric Auxiliary Contact Block, TeSys D, 1NO + 1NC, Front Mounting, Screw TerminalsSpecial Price EGP 546 Regular Price EGP 1,012
Schneider Electric Auxiliary Contact Block, TeSys D, 2NO/2NC, Front Mounting, Screw TerminalsSpecial Price EGP 810 Regular Price EGP 1,499
Schneider Electric Thermal Overload Relay, 4-6 A, Class 10ASpecial Price EGP 2,024 Regular Price EGP 3,748
Schneider Electric Thermal Overload Relay, 9-13 A, Class 10ASpecial Price EGP 2,268 Regular Price EGP 4,200
Schneider Electric TeSys D Contactor, 3P, 3NO, AC3 440V, 18A, 380V AC CoilSpecial Price EGP 1,938 Regular Price EGP 3,590
Schneider Electric Contactor, Tesys D, 3P (3 Poles), 32A AC3, 440V, 220V AC CoilSpecial Price EGP 3,238 Regular Price EGP 5,996
Schneider Electric Tesys D Contactor, 3P, 3NO, AC3 440V, 80A, 110V AC 50/60Hz CoilSpecial Price EGP 9,720 Regular Price EGP 18,001
TeSys K control relay, 4 contacts (4NO), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides 220/230V 50/60Hz AC coil as standard coil for control circuit, connection by spring terminals.
Specifications:
| Main | |
| Range | TeSys |
| Product name | TeSys CAK |
| Product or component type | Control relay |
| Device short name | CA2K |
| Contactor application | Control circuit |
| Utilisation category | AC-15 |
| DC-13 | |
| Pole contact composition | 4 NO |
| [Ue] rated operational voltage | <= 690 V <= 400 Hz |
| Control circuit type | AC at 50/60 Hz |
| [Uc] control circuit voltage | 220...230 V AC 50/60 Hz |
| Complementary | |
| [Ith] conventional free air thermal current | 10 A (at 50 °C) |
| Irms rated making capacity | 110 A conforming to IEC 60947 |
| Associated fuse rating | 10 A gG conforming to IEC 60947 |
| 10 A gG conforming to VDE 0660 | |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947 |
| 750 V conforming to VDE 0110 group C | |
| 690 V conforming to BS 5424 | |
| 600 V conforming to CSA C22.2 No 14 | |
| Mounting support | Plate |
| Rail | |
| Connections - terminals | Screw clamp terminals 1 cable(s) 1.5…4 mm²solid |
| Screw clamp terminals 2 cable(s) 1.5…4 mm²solid | |
| Screw clamp terminals 1 cable(s) 0.75…4 mm²flexible with cable end | |
| Screw clamp terminals 2 cable(s) 0.75…4 mm²flexible without cable end | |
| Screw clamp terminals 1 cable(s) 0.34…1.5 mm²flexible with cable end | |
| Screw clamp terminals 2 cable(s) 0.34…1.5 mm²flexible without cable end | |
| Tightening torque | 1.3 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm |
| 1.3 N.m - on screw clamp terminals - with screwdriver Philips No 26 mm | |
| 1.3 N.m - on screw clamp terminals - with screwdriver pozidriv No 2 | |
| Control circuit voltage limits | Drop-out: 0.2...0.75 Uc (at <50 °C) |
| Operational: 0.8...1.15 Uc (at <50 °C) | |
| Operating time | 10...20 ms coil de-energisation and NO opening |
| 10...20 ms coil energisation and NO closing | |
| Mechanical durability | 10 Mcycles |
| Maximum operating rate | 10000 cyc/h |
| Immunity to microbreaks | 2 ms |
| Inrush power in VA | 30 VA (at 20 °C) |
| Hold-in power consumption in VA | 4.5 VA (at 20 °C) |
| Heat dissipation | 1.3 W |
| Minimum switching voltage | 17 V |
| Minimum switching current | 5 mA |
| Non overlap distance | 0.5 mm |
| Insulation resistance | > 10 MOhm |
| Height | 58 mm |
| Width | 45 mm |
| Depth | 57 mm |
| Net weight | 0.18 kg |
| Environment | |
| Standards | EN/IEC 60947-5-1 |
| GB/T 14048.5 | |
| UL 60947-5-1 | |
| CSA C22.2 No 60947-5-1 | |
| JIS C8201-5-1 | |
| Product certifications | CB Scheme |
| CCC | |
| UL | |
| CSA | |
| EAC | |
| CE | |
| UKCA | |
| IP degree of protection | IP2X |
| Protective treatment | TC conforming to IEC 60068 |
| Ambient air temperature for operation | -25…50 °C |
| Ambient air temperature for storage | -50…80 °C |
| Operating altitude | 2000 m without derating |
| Flame retardance | V1 conforming to UL 94 |
| Requirement 2 conforming to NF F 16-101 | |
| Requirement 2 conforming to NF F 16-102 | |
| Mechanical robustness | Vibrations contactor open: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 |
| Vibrations contactor closed: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6 | |
| Shocks contactor open: 10 Gn for 11 ms conforming to IEC 60068-2-27 | |
| Shocks contactor closed: 15 Gn for 11 ms conforming to IEC 60068-2-27 |
| Weight | 3.000000 |
|---|---|
| Brand | Schneider Electric |
| Model | CA2KN40M7 |
| Color | Black |
| Device Application | Control |
| Depth [cm] | 5.7 |
| Width [cm] | 4.5 |
| Height [cm] | 5.8 |
| Range | Tesys D |
| Family | PPCTR |
| Type | Control relay |
| Poles | 4P |
| IP Degree of Protection | IP2X |
