Motor Circuit Breaker - EasyPact TVS - AC3 3P - 0.1-0.16A - Thermal-Magnetic Detection, Schneider Electric

In stock
SKU
GZ1E01
Special Price EGP 1,064 Regular Price EGP 1,971
Quick Overview

Range of product: EasyPact
Product type: Circuit breaker
Poles: 3P
Device application: Motor

The GZ1E01 Motor Circuit Breaker, a part of Schneider Electric's EasyPact TVS series, is a reliable solution for motor protection and circuit disconnection. This 3-pole circuit breaker is designed to handle currents ranging from 0.1 to 0.16 amperes. Equipped with thermal-magnetic detection, it offers enhanced safety and protection for your electrical circuits and motors.



Key Features:

Motor Protection: The GZ1E01 is specifically designed to protect motors from overloads and short circuits, ensuring the longevity of your motor-driven equipment.

3-Pole Design: With a 3-pole configuration, this circuit breaker provides comprehensive protection for three-phase electrical systems.

Current Range: This breaker supports a current range of 0.1 to 0.16 amperes, making it suitable for low-current applications.

Thermal-Magnetic Detection: The thermal-magnetic detection mechanism ensures a quick response to overcurrents, offering reliable protection to your circuits.

Robust Build: Schneider Electric's quality construction ensures a long-lasting and durable motor circuit breaker.



Technical Specifications:

Product Type: Motor Circuit Breaker

Series: EasyPact TVS

Configuration: 3P (3-Pole)

Current Rating: 0.1-0.16A

Detection: Thermal-Magnetic



Specifications

Main
RangeEasy TeSys
Range of productEasy TeSys Power
Product or component typeCircuit breaker
device short nameGZ1E
Device applicationMotor
Trip unit technologyThermal-magnetic
Suitability for isolationYes conforming to IEC 60947-1 appendix 7.1.6
ColourGrey (RAL 7011)
Complementary
Poles description3P
Network typeAC
Utilisation categoryAC-3
Network frequency50/60 Hz conforming to IEC 60947-2
Mounting modeBy screws
By clips
mounting supportRail
Mounting positionAny position
Breaking capacityIcu: >= 100 kA at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
Icu: >= 100 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
Icu: >= 100 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
Icu: >= 100 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
Icu: >= 100 kA at 690 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service short-circuit breaking capacity100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
100 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
100 % at 440 V AC 50/60 Hz conforming to IEC 60947-2
100 % at 500 V AC 50/60 Hz conforming to IEC 60947-2
100 % at 690 V AC 50/60 Hz conforming to IEC 60947-2
control typePush-button
Thermal protection adjustment range0.1…0.16 A
Magnetic tripping current1.5 A
[Ue] rated operational voltage690 V AC 50/60 Hz conforming to IEC 60947-2
[Ui] rated insulation voltage690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage6 kV conforming to IEC 60947-2
Power dissipation2.5 W (per pole)
Mechanical durability100000 cycles
Electrical durability100000 cycles for AC-3
Maximum operating rate25 cyc/h
Connections - terminalsScrew clamp terminals 2 1…6 mm² - cable stiffness: solid
Screw clamp terminals 2 1.5…6 mm² - cable stiffness: flexible without cable end
Screw clamp terminals 2 1…4 mm² - cable stiffness: flexible with cable end
height89 mm
Width44.5 mm
Depth78 mm
Net weight0.26 kg
Environment
standardsIEC 60947-4
IEC 60947-2
Protective treatmentTH
IP degree of protectionIP20 conforming to IEC 60529
Ambient air temperature for operation-20…60 °C
Ambient air temperature for storage-40…80 °C
Fire resistance960 °C conforming to IEC 60695-2-1
Operating altitude2000 m
More Information
BrandSchneider Electric
ModelGZ1E01
Depth [cm]7.8
Width [cm]0.26
Height [cm]8.9
RangeEasy TeSys
