APC SMV 3000VA Easy UPS Line-interactive 230V, 4 Schuko Outlets
Capacity: 3000VA / 2100W
Power Factor: 0.7
Transfer time: 2-6 ms typical : 12 ms maximum
Output Connection type: 4 Schuko CEE 7
The SMV3000AI-GR is a high-capacity uninterruptible power supply (UPS) designed to provide reliable power protection for your critical devices and data. With a capacity of 3000VA, this UPS is ideal for servers, networking equipment, and other sensitive electronics.
Key Features:
Double-Conversion Technology: The UPS uses double-conversion technology to provide clean and stable power to your equipment, protecting it from voltage fluctuations, surges, and outages.
Scalable Runtime: You can extend the runtime of the UPS by adding external battery packs, ensuring your devices stay powered during longer outages.
LCD Display: The built-in LCD display provides real-time information about the UPS status, allowing you to monitor power conditions easily.
Intelligent Battery Management: The UPS includes intelligent battery management for optimized battery performance and longer lifespan.
Smart UPS Applications:
Servers/Server Rooms
- Entry level
- Rack optimized
- Appliances
- Storage
Networking Telecom/Wiring Closets
- Switches
- Routers
- Gateways
- MDF/IDF
- PBX/IP PBX
Retail Stores/ Financial branches
- Point-of-sale (POS)
- ATM
- Kiosk
- Back Office
Other
- Security devices
- Workstations
- Medical and laboratory equipment
Specifications:
Main Input Voltage | 230 V |
Input voltage | 220 V |
240 V | |
Main Output Voltage | 230 V |
Rated power in W | 2100 W |
Rated power in VA | 3000 VA |
Input Connection Type | IEC 60320 C20 |
output connection type | 4 Schuko CEE 7 |
Number of cables | 1 |
Battery type | Lead-acid battery |
Provided equipment | Documentation CD |
User manual | |
USB cable | |
Batteries & Runtime | |
Number of battery filled slots | 0 |
Number of battery free slots | 0 |
Battery recharge time | 4 h |
Battery voltage | 48 V |
Battery charger power | 99 W rated |
Battery life | 3…5 year(s) |
Extended runtime | 0 |
General | |
Number of power module free slots | 0 |
Number of power module filled slots | 0 |
Redundant | No |
UPS size | WS |
Physical | |
Colour | Black |
height | 24 cm |
Width | 18 cm |
Depth | 45.5 cm |
Net weight | 25.2 kg |
Mounting preference | No preference |
Mounting mode | Not rack-mountable |
Two post mountable | 0 |
USB compatible | No |
Input | |
Network frequency | 45...65 Hz +/- 1 Hz auto-sensing |
Input voltage limits | 165...295 V |
Output | |
Maximum configurable power in W | 2100 W |
Output frequency | 50/60 Hz +/- 1 Hz unsynchronised |
Crest factor | 3:01 |
UPS type | Line interactive |
Wave type | Sine wave |
Graph display | 1 |
Maximum configurable power in VA | 3000 VA |
Transfer time | 2-6 ms typical : 12 ms maximum |
Conformance | |
product certifications | CE |
Standards | EN/IEC 62040-1:2019/A11:2021 |
EN/IEC 62040-2:2006/AC:2006 | |
EN/IEC 62040-2:2018 | |
Environmental | |
Ambient air temperature for operation | 0…40 °C |
Relative humidity | 0…95 % non-condensing |
Operating altitude | 0...3000 m |
Ambient air temperature for storage | -10…40 °C |
Storage Relative Humidity | 0…95 % non-condensing |
Storage altitude | 0…15000 m |
Acoustic level | 45 dBA |
IP degree of protection | IP20 |
Communications & Management | |
Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge Protection and Filtering | |
Surge energy rate | 125 J |
| Weight | 25.200000 |
|---|---|
| Brand | APC |
| Model | SMV3000AI-GR |
| Color | Black |
| Depth [cm] | 45.5 |
| Width [cm] | 18 |
| Height [cm] | 24 |
| Range | SMV |
| Rated Power in VA | 3000 VA |
| Rated Power In W | 2100 Watt |
| Power Factor | 0.7 |
| Transfer Time | 2-6 ms typical : 12 ms maximum |
| Input Voltage | 230 V |
| Output Voltage | 230 V |
