APC SMV 1000VA Easy UPS Line-interactive 230V, 4 Schuko Outlets
Capacity: 1000VA/700W
Power Factor: 0.7
Transfer Time: 2-6 ms typical : 12 ms maximum
Output Connection type: 4 Schuko CEE 7
APC SMV1000I-GR 1000VA/700W LINE-INTERACTIVE 230V SCHUKO OUTLET EASY UPS
Optimal UPS with battery backup and surge protection for electronics and computers.
The APC SMV1000I-GR is a line-interactive Uninterruptible Power Supply (UPS) with a 1000VA/600W capacity. It is designed to protect connected equipment from power surges, spikes, and other power disturbances that can cause damage or data loss. The UPS is equipped with Schuko outlets, which are commonly used in Europe and other regions using 230V power.
The APC SMV1000I-GR is an ideal UPS solution for safeguarding electronics and computers. It operates in a line-interactive manner, providing 1000VA/700W capacity. With Schuko outlets designed for 230V power, it offers optimal protection against power surges, spikes, and other disturbances that could potentially harm your equipment or result in data loss. Additionally, it incorporates battery backup functionality to ensure uninterrupted power supply during outages.
The "line-interactive" design of the UPS means that it uses an automatic voltage regulator (AVR) to correct minor power fluctuations without switching to battery power. This helps to extend the battery life and reduce wear on the UPS.
The SMV1000I-GR also features an LCD display that provides real-time information on the UPS status, including input/output voltage, battery capacity, and estimated runtime. The UPS has a built-in battery that can provide backup power for up to 10 minutes at full load, or longer at lower loads.
The "Easy UPS" designation indicates that this UPS is designed for easy installation and maintenance. It features a hot-swappable battery that can be easily replaced without interrupting power to connected equipment. The UPS also has a compact and lightweight design, making it easy to install and move as needed.
The APC SMV1000I-GR is a reliable and easy-to-use UPS that provides basic protection for connected equipment from power disturbances. It is suitable for use in home and small office environments.
Smart-UPS Applications:
Servers/Server Rooms
- Entry level
- Rack optimized
- Appliances
- Storage
Networking Telecom/Wiring Closets
- Switches
- Routers
- Gateways
- MDF/IDF
- PBX/IP PBX
Retail Stores/ Financial branches
- Point-of-sale (POS)
- ATM
- Kiosk
- Back Office
Other
- Security devices
- Workstations
- Medical and laboratory equipment
Specifications:
Main | |
Main Input Voltage | 230 V |
Input voltage | 220 V |
240 V | |
Main Output Voltage | 230 V |
Rated power in W | 700 W |
Rated power in VA | 1000 VA |
Input Connection Type | IEC 60320 C14 |
output connection type | 4 Schuko CEE 7 |
Number of cables | 1 |
battery type | Lead-acid battery |
Provided equipment | Documentation CD |
User manual | |
USB cable | |
Batteries & Runtime | |
Number of battery filled slots | 0 |
Number of battery free slots | 0 |
Battery recharge time | 4 h |
battery voltage | 24 V |
Battery charger power | 37 W rated |
Battery life | 3…5 year(s) |
Extended runtime | 0 |
General | |
Number of power module free slots | 0 |
Number of power module filled slots | 0 |
Redundant | No |
UPS size | WS |
Physical | |
Colour | Black |
Mounting preference | No preference |
Mounting mode | Not rack-mountable |
Two post mountable | 0 |
USB compatible | No |
Input | |
Network frequency | 45...65 Hz auto-sensing |
Input voltage limits | 165...290 V |
Output | |
Maximum configurable power in W | 700 W |
Output frequency | 50/60 Hz +/- 1 Hz unsynchronised |
Crest factor | 3:01 |
UPS type | Line interactive |
Wave type | Sine wave |
Graph display | 1 |
Maximum configurable power in VA | 1000 VA |
Transfer time | 2-6 ms typical : 12 ms maximum |
Conformance | |
product certifications | CE |
Standards | EN/IEC 62040-1:2019/A11:2021 |
EN/IEC 62040-2:2006/AC:2006 | |
EN/IEC 62040-2:2018 | |
Environmental | |
Ambient air temperature for operation | 0…40 °C |
Relative humidity | 0…95 % non-condensing |
Operating altitude | 0...3000 m |
Ambient air temperature for storage | -10…40 °C |
Storage Relative Humidity | 0…95 % non-condensing |
Storage altitude | 0…15000 m |
Acoustic level | 45 dBA |
IP degree of protection | IP20 |
Communications & Management | |
Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge Protection and Filtering | |
Surge energy rate | 190 J |
Weight | 13.600000 |
---|---|
Brand | APC |
Model | SMV1000I-GR |
Color | Black |
Depth [cm] | 41 |
Width [cm] | 16 |
Height [cm] | 22 |
Range | SMV |
Rated Power in VA | 1000 VA |
Rated Power In W | 700 Watt |
Power Factor | 0.7 |
Transfer Time | 2-6 ms typical : 12 ms maximum |
Input Voltage | 230 V |
Output Voltage | 230 V |
