main product photo

Schneider Electric Variable Speed Drive Altivar 12, 0.55 kW (0.75 HP), 200-240V, 1-Phase with Heat Sink

Be the first to review this product
Out of stock
SKU
ATV12H055M2
Schneider Electric
Special Price EGP 7,618 Regular Price EGP 13,851
Estimated Time of Delivery is 72 Hours.
Ship to EGCalculate Shipping Cost

Installment Plans

The Installment Amount Is Approximate. The Actual Amount Will Be Shown During The Payment Process.

  • Bank Installment
  • Direct Installment
Add to Compare
Quick Overview

Range of product: Altivar 12
Product type: Variable speed drive
Product specific application: Simple machine
Mounting Mode: Cabinet mount

The ATV12H055M2 Variable Speed Drive Altivar 12 is a powerful and efficient motor drive designed for a wide range of applications. With a power rating of 0.55 kW (0.75 HP) and compatibility with 200-240V single-phase power systems, it provides precise control over motor speed and performance. This drive is equipped with a heat sink for optimal thermal management, ensuring reliable operation.



Key Features:

Precise Speed Control: The Altivar 12 drive offers precise control over the speed and performance of your motor, making it suitable for a variety of applications.

Single-Phase Compatibility: Designed for use with 200-240V single-phase power systems, making it versatile and easy to install.

Thermal Management: The integrated heat sink helps maintain the drive's temperature, ensuring reliable and efficient operation.

Compact Design: Its compact size allows for easy installation even in tight spaces.



Technical Specifications:

Product Type: Variable Speed Drive

Power Rating: 0.55 kW (0.75 HP)

Voltage Rating: 200-240V

Phase: 1-Phase

Thermal Management: With Heat Sink



Specifications

Main


Range of ProductAltivar 12
Product or Component TypeVariable speed drive
Product Specific ApplicationSimple machine
Mounting ModeCabinet mount
Communication Port ProtocolModbus
Supply frequency50/60 Hz +/- 5 %
[Us] rated supply voltage200...240 V - 15...10 %
Nominal output current3.5 A
Maximum Horse Power Rating0.75 hp
Motor power kW0.55 kW
Maximum Horse Power Rating0.75 hp
EMC filterIntegrated
IP degree of protectionIP20
Complementary
Discrete input number٤
Discrete output number٢
analogue input number١
analogue output number١
Relay output number١
Physical interface2-wire RS 485
Connector Type1 RJ45
Continuous output current3.5 A 4 kHz
Method of accessServer Modbus serial
Speed drive output frequency0.5…400 Hz
Speed range1…20
Sampling duration20 ms +/- 1 ms logic input
 10 ms analogue input
Linearity error+/- 0.3 % of maximum value analogue input
Frequency resolutionAnalog input converter A/D, 10 bits
 Display unit 0.1 Hz
Time constant20 ms +/- 1 ms for reference change
Transmission Rate9.6 kbit/s
 19.2 kbit/s
 38.4 kbit/s
Transmission frameRTU
Number of addresses1…247
Data format8 bits, configurable odd, even or no parity
Communication serviceRead holding registers (03) 29 words
 Write single register (06) 29 words
 Write multiple registers (16) 27 words
 Read/write multiple registers (23) 4/4 words
 Read device identification (43)
Type of polarizationNo impedance
4 quadrant operation possibleFALSE
Asynchronous motor control profileVoltage/frequency ratio (V/f)
 Quadratic voltage/frequency ratio
 Sensorless flux vector control
Maximum output frequency4 kHz
Transient overtorque150…170 % of nominal motor torque depending on drive rating and type of motor
Acceleration and deceleration rampsLinear from 0 to 999.9 s
 S
 U
Motor slip compensationPreset in factory
 Adjustable
Switching frequency2...16 kHz adjustable
 4...16 kHz with derating factor
Nominal switching frequency4 kHz
Braking to standstillBy DC injection
Brake chopper integratedFALSE
Line current8.0 A 100 V heavy duty)
 6.7 A 120 V heavy duty)
Maximum Input Current per Phase6.7 A
Maximum output voltage240 V
Apparent power1.6 kVA 240 V heavy duty)
Maximum transient current5.3 A 60 s heavy duty)
 5.8 A 2 s heavy duty)
Network Frequency50-60 Hz
Relative symmetric network frequency tolerance٠
Prospective line Isc1 kA
Base load current at high overload3.5 A
Power dissipation in WNatural 34.0 W
With safety function Safely Limited Speed (SLS)FALSE
With safety function Safe brake management (SBC/SBT)FALSE
With safety function Safe Operating Stop (SOS)FALSE
With safety function Safe Position (SP)FALSE
With safety function Safe programmable logicFALSE
With safety function Safe Speed Monitor (SSM)FALSE
With safety function Safe Stop 1 (SS1)FALSE
With sft fct Safe Stop 2 (SS2)FALSE
With safety function Safe torque off (STO)FALSE
With safety function Safely Limited Position (SLP)FALSE
With safety function Safe Direction (SDI)FALSE
Protection typeLine supply overvoltage
 Line supply undervoltage
 Overcurrent between output phases and earth
 Overheating protection
 Short-circuit between motor phases
 Against input phase loss in three-phase
 Thermal motor protection via the drive by continuous calculation of I²t
tightening torque7.08 lbf.in (0.8 N.m)
insulationElectrical between power and control
Quantity per SetSet of 1
Width2.83 in (72 mm)
Height5.63 in (143 mm)
Depth5.17 in (131.2 mm)
Net Weight1.76 lb(US) (0.8 kg)
Environment
Operating altitude> 3280.84...6561.68 ft (> 1000...2000 m) with current derating 1 % per 100 m
 <= 3280.84 ft (1000 m) without derating
Operating positionVertical +/- 10 degree
Product CertificationsNOM
 CSA
 C-tick
 UL
 GOST
 RCM
 KC
MarkingCE
standardsUL 508C
 UL 618000-5-1
 EN/IEC 61800-5-1
 EN/IEC 61800-3
Assembly styleWith heat sink
Electromagnetic compatibilityElectrical fast transient/burst immunity test level 4 EN/IEC 61000-4-4
 Electrostatic discharge immunity test level 3 EN/IEC 61000-4-2
 Immunity to conducted disturbances level 3 EN/IEC 61000-4-6
 Radiated radio-frequency electromagnetic field immunity test level 3 EN/IEC 61000-4-3
 Surge immunity test level 3 EN/IEC 61000-4-5
 Voltage dips and interruptions immunity test EN/IEC 61000-4-11
Environmental class (during operation)Class 3C3 according to IEC 60721-3-3
 Class 3S2 according to IEC 60721-3-3
Maximum acceleration under shock impact (during operation)150 m/s² at 11 ms
Maximum acceleration under vibrational stress (during operation)10 m/s² at 13...200 Hz
Maximum deflection under vibratory load (during operation)1.5 mm at 2...13 Hz
Overvoltage categoryClass III
Regulation loopAdjustable PID regulator
Electromagnetic emissionRadiated emissions environment 1 category C2 EN/IEC 61800-3 2...16 kHz shielded motor cable
 Conducted emissions with integrated EMC filter environment 1 category C1 EN/IEC 61800-3 2, 4, 8, 12 and 16 kHz shielded motor cable <16.40 ft (5 m)
 Conducted emissions with integrated EMC filter environment 1 category C2 EN/IEC 61800-3 2...12 kHz shielded motor cable <16.40 ft (5 m)
 Conducted emissions with integrated EMC filter environment 1 category C2 EN/IEC 61800-3 2, 4 and 16 kHz shielded motor cable <32.81 ft (10 m)
 Conducted emissions with additional EMC filter environment 1 category C1 EN/IEC 61800-3 4...12 kHz shielded motor cable <65.62 ft (20 m)
 Conducted emissions with additional EMC filter environment 1 category C2 EN/IEC 61800-3 4...12 kHz shielded motor cable <164.04 ft (50 m)
 Conducted emissions with additional EMC filter environment 2 category C3 EN/IEC 61800-3 4...12 kHz shielded motor cable <164.04 ft (50 m)
Vibration resistance1 gn 13…200 Hz)EN/IEC 60068-2-6
 1.5 mm peak to peak 3…13 Hz) - drive unmounted on symmetrical DIN rail - EN/IEC 60068-2-6
Shock resistance15 gn 11 ms EN/IEC 60068-2-27
Relative humidity5…95 % without condensation IEC 60068-2-3
 5…95 % without dripping water IEC 60068-2-3
Noise level0 dB
Pollution degree2







More Information
Weight0.800000
BrandSchneider Electric
ModelATV12H055M2
Depth [cm]13.12
Width [cm]7.2
Height [cm]14.3
RangeATV12
FamilyIDVSD
