Schneider Electric TeSys GB2 Thermal Magnetic Circuit Protector, 1P, 2A, ID 26A
In stock
SKU
GB2CB07
Special Price EGP 1,581 Regular Price EGP 2,874
Schneider Electric TeSys GB2 Thermal Magnetic Circuit Protector, 1P, 2A, ID 26A is available to buy in increments of 1
Quick Overview
Range: TeSys
Product type: Circuit breaker
Device application: Control
Poles: 1P
TeSys GB circuit breaker, 1 pole (1P), 2A/250V IEC/277V UL, for the protection of industrial equipment control circuits. It provides thermal-magnetic protection with a magnetic tripping level at 26A (13 In) and breaking capacity Icu 15kA@240V. It can also be used for protection of DC loads up to 2A/48V DC-13 with a breaking capacity Icu 1.5kA@24V. Compact device (15mm wide), mounting on 35mm DIN-rail, control by toggle lever (start-stop guaranteed for 8000 cycles). Sold in lots of 6 units. Multi standards certified (IEC, UL, CSA).
Specifications:
| Main | |
| Range | TeSys |
| product name | TeSys GB2 |
| Device short name | GB2 |
| Product or Component Type | Circuit breaker |
| Device Application | Control |
| Poles description | 1P |
| Network type | AC/DC |
| Utilisation category | Category A IEC 60947-2 |
| DC-12 IEC 60947-5-1 | |
| DC-13 IEC 60947-5-1 | |
| Network frequency | 50/60 Hz IEC 60947-2 |
| Breaking capacity | 15 kA Icu 110 V AC 50/60 Hz IEC 60947-2 |
| 15 kA Icu 230/240 V AC 50/60 Hz IEC 60947-2 | |
| 1.5 kA Icu 24 V DC IEC 60947-2 | |
| 1 kA Icu 48 V DC IEC 60947-2 | |
| [Ics] rated service short-circuit breaking capacity | 25 % 230/240 V AC 50/60 Hz IEC 60947-2 |
| 50 % 110 V AC 50/60 Hz IEC 60947-2 | |
| Trip unit technology | Thermal-magnetic |
| Magnetic tripping current | 26 A |
| Complementary | |
| Mounting Mode | By clips |
| Mounting Support | Rail |
| Plate | |
| Mounting position | Horizontal |
| Vertical | |
| Control Type | Toggle |
| Line Rated Current | 2:00 AM |
| [Ue] rated operational voltage | 250 V AC 50/60 Hz IEC 60947-2 |
| 277 V AC 60 Hz CSA C22.2 No 235 | |
| 277 V AC 60 Hz UL 1077 | |
| 48 V DC | |
| [Uimp] rated impulse withstand voltage | 4 kV IEC 60947-2 |
| Power dissipation per pole | 2 W |
| Mechanical durability | 8000 cycles |
| Electrical durability | 8000 cycles |
| Connections - terminals | connector 1 0.001…0.009 in² (0.75…6 mm²)solid without cable end |
| connector 2 0.001…0.006 in² (0.75…4 mm²)solid without cable end | |
| connector 1 0.001…0.006 in² (0.75…4 mm²)flexible with cable end | |
| connector 2 0.001…0.004 in² (0.75…2.5 mm²)flexible with cable end | |
| Tightening torque | 10.6 lbf.in (1.2 N.m) connector |
| Mechanical robustness | Shocks 22 Gn for 20 ms IEC 60068-2-27 |
| Vibrations 5 Gn, 5...110 Hz IEC 60068-2-6 | |
| Quantity per Set | Set of 6 |
| 9 mm pitches | 2 |
| Height | 2.9 in (74 mm) |
| Width | 0.6 in (15 mm) |
| Depth | 2.6 in (67 mm) |
| Environment | |
| Standards | EN/IEC 60947-1 |
| EN/IEC 60947-2 | |
| CSA C22.2 No 235 | |
| UL 1077 | |
| Product Certifications | UL |
| CSA | |
| Protective treatment | TC |
| IP degree of protection | IP20 IEC 60529 |
| Ambient air temperature for operation | -4…140 °F (-20…60 °C) |
| Ambient Air Temperature for Storage | -40…176 °F (-40…80 °C) |
| Fire resistance | 1760 °F (960 °C) IEC 60695-2-1 |
| Operating altitude | 9842.52 ft (3000 m) |
| Ordering and shipping details | |
| Category | US1000I22631 |
| Discount Schedule | 000I |
| GTIN | 3.38911E+12 |
| Returnability | Yes |
| Country of origin | FR |
| Weight | 0.005300 |
|---|---|
| Brand | Schneider Electric |
| Model | GB2CB07 |
| Color | White |
| Range | CTR Others |
| Family | PPCTR |
| Type | Circuit Breaker |
| Poles | 1P |
| Voltage ~ Frequency | 50-60 Hz |
| IP Degree of Protection | IP20 |
