Schneider Electric Adjustable Time Delay Relay For Voltage Release MN - 200/250 V AC/DC
In stock
SKU
33682
Special Price EGP 14,694 Regular Price EGP 22,264
Schneider Electric Adjustable Time Delay Relay For Voltage Release MN - 200/250 V AC/DC is available to buy in increments of 1
Quick Overview
Product type: Time delay relay
Device application: Control
Impulse duration: 200 ms
Time delay range: 0.5...3 s
This time delay unit is an auxiliary that can be combined with an undervoltage release (MN). It must be associated with a 250VDC MN undervoltage release. It eliminates the risk of nuisance tripping due to transient voltage dips lasting from 200ms to 3s. Its power supply is 200-250VDC or 200-250VAC 50/60Hz. This time delay unit has 4 adjustable steps (0.5s - 1s - 1.5s - 3s). It is an external accessory and can be mounted in the switchboard.
Specifications:
| Main | |
| Device short name | MN delay unit |
| Product or component type | Time delay relay |
| Device application | Control |
| Range compatibility | Masterpact MasterPact NT |
| Masterpact MasterPact NW | |
| ComPact ComPact NSX | |
| ComPact ComPact NS630b...1600 | |
| ComPact ComPact NS1600b...3200 | |
| PowerPact PowerPact Multistandard | |
| ComPact ComPact NSXm | |
| ComPact ComPact NSX DC | |
| Masterpact MasterPact NW UL 489 | |
| Masterpact MasterPact NT UL 489 | |
| Masterpact MasterPact NW DC | |
| Voltage release type | Undervoltage release |
| [Uc] control circuit voltage | 200...250 V AC 50/60 Hz |
| 200...250 V DC | |
| Complementary | |
| Impulse duration | 200 ms |
| Time delay range | 0.5...3 s |
| Threshold tripping voltage | 0.35...0.7 Un open |
| 0.85 Un close | |
| Supply holding power | 4.5 VA |
| Supply inrush power | 200 VA |
| Mounting mode | External mounting |
| Response time | 0.5 s |
| 1 s | |
| 1.5 s | |
| 3 s | |
| Accessory / separate part category | Spare part for Compact NS630b...1600 |
| Spare part for Compact NS1600b...3200 |
| Weight | 3.000000 |
|---|---|
| Brand | Schneider Electric |
| Model | 33682 |
| Range | PROXAccessories |
| Family | PPACB |
