Push Button Station, Two-Button, Start/Stop, 1NO/1NC, IP66, Schneider Electric
Range of product: Harmony XB4
Product type: Push-button
Type of operator: Spring return
Shape of signaling unit head: Round
Introducing the Schneider Electric XACA9411 Push Button Station – a robust and reliable solution for your industrial control needs. This station features two buttons, one for start and the other for stop functions. It comes equipped with 1 normally open (NO) and 1 normally closed (NC) contact, ensuring versatile control options. With an IP66 rating, it offers protection against dust and water ingress, making it suitable for a wide range of industrial applications.
Key Features:
Two-Button Control: The XACA9411 features a two-button layout for easy start and stop control, enhancing safety and efficiency.
1NO/1NC Contacts: With both normally open and normally closed contacts, this station offers flexibility in control applications.
IP66 Rated: This push button station is rated IP66, providing protection against dust and water, making it suitable for harsh industrial environments.
Robust Construction: Built with high-quality materials, it can withstand tough operating conditions.
Technical Specifications:
Buttons: Two (Start and Stop)
Contacts: 1NO/1NC
IP Rating: IP66
Specifications
| Main | |
| Range of product | Harmony XAC |
| Product or component type | Head for push-button |
| component name | XACA |
| Complementary | |
| Marking | Unmarked |
| Operator additional information | Booted |
| Cap/operator or lens colour | White |
| Product compatibility | XACA.. |
| Mounting location | Front of enclosure |
| Sale per indivisible quantity | 10 |
| standards | CSA C22.2 No 14 |
| IEC 60947-5-1 | |
| IEC 60204-32 | |
| UL 508 | |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -40…70 °C |
| Vibration resistance | 15 gn (f= 10…500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 100 gn conforming to IEC 60068-2-27 |
| Overvoltage category | Class II conforming to IEC 61140 |
| IP degree of protection | IP65 conforming to IEC 60529 |
| IK degree of protection | IK08 conforming to IEC 62262 |
| Net weight | 0.01 kg |
| Weight | 0.010000 |
|---|---|
| Brand | Schneider Electric |
| Model | XACA9411 |
| Color | White |
| Range | PendantStations |
| Family | IDSIG |
