Disconnect Switch, Miluz E, 32AX, 250V, 2 Module, White

This Schneider Electric Miluz E device is a 1 Way Disconnect Switch 250V 32AX 2 module white. It is a double pole switch, 2 rockers and 2 module size. It has good wiring capacity for flexible, stranded and rigid cable with 10 sq.mm, 6 sq.mm and 4 sq.mm cable cross section. The wire stripping length is 12 mm. Its Ue operating voltage of 250VAC and current rating of 32A. This device enables flush mounting with click-in fixing mode and folded terminals. The dimensions are (W) 45mm x (H) 45mm x (D) 33.2mm. Projecting depth is 21mm and having 57.9g weight. The color of this device is white. It is made of polycarbonate material. The operating temperature is from -5°C up to +40°C and reaches IP20 degree of protection. This device comes in plastic bag packing. All Miluz ED products meet the latest standards and are made out of high-quality materials to reach a long life-cycle and satisfy their end-users daily. Miluz ED products are intuitive to use and provide the possibility of unique lighting ambiances and comfort at all times. This device is compliant with IEC 60669-1 and IEC certification.

Specifications:
