Compact NSX100F Circuit Breaker, 36kA at 415VAC, Micrologic, 3 Poles, TMD trip unit 16A
Product or component type: Circuit breaker
Device application: Distribution
Number of poles: 3P
[in] Rated Current: 16 A at 40 °C
Introducing the Schneider Electric Compact NSX100F Circuit Breaker, a reliable and high-performance solution for circuit protection. Engineered to ensure the safety and efficiency of your electrical systems, this circuit breaker offers robust protection capabilities, making it suitable for a variety of applications.
Key Features:
High Breaking Capacity: With an impressive 36kA breaking capacity at 415VAC, this circuit breaker can handle high fault currents, enhancing the safety of your electrical circuits.
3 Poles: The 3-pole configuration adds versatility to your electrical system, making it suitable for various applications and installations.
Micrologic 2.2 Trip Unit: Equipped with the advanced Micrologic 2.2 trip unit, this circuit breaker offers intelligent protection with enhanced features for precise fault detection and response.
40A Rating: The 40A rating allows this circuit breaker to handle moderate electrical loads while providing reliable protection.
3D Compatibility: The 3D designation signifies its compatibility with a range of tripping units, ensuring flexible protection options.
Technical Specifications:
Breaking Capacity: 36kA at 415VAC
Poles: 3
Trip Unit Type: Micrologic 2.2
Current Rating: 40A
Tripping Units Compatibility: 3D
| Weight | 2.050000 |
|---|---|
| Brand | Schneider Electric |
| Model | C10F3TM016 |
| Device Application | Distribution |
| Depth [cm] | 8.6 |
| Width [cm] | 10.5 |
| Height [cm] | 16.1 |
| Range | NSX |
| Family | PPCCB |
| Type | Circuit Breaker |
| Poles | 3P |
| [In] Rated Current | 16 A at 40 °C |
