Schneider Electric Circuit Breaker ComPacT NSXm B (25kA at 415VAC), 4 Poles 3d, 25A
In stock
SKU
C11B6TM025L
Special Price EGP 11,783 Regular Price EGP 17,852
Schneider Electric Circuit Breaker ComPacT NSXm B (25kA at 415VAC), 4 Poles 3d, 25A is available to buy in increments of 1
Quick Overview
Range: ComPacT
Product type: Circuit breaker
Device application: Distribution
Poles: 4P
You May Also Like:
Schneider Electric Front Rotary Handle, Black Handle for NS630b-1600Special Price EGP 6,742 Regular Price EGP 10,214
Schneider Electric Circuit Breaker Compact Nsx400F, 36 Ka At 415 Vac, Micrologic 2.3 Trip Unit 400 A, 3 Poles 3DSpecial Price EGP 41,834 Regular Price EGP 63,869
It is a ComPacT NSXm molded case circuit breaker, 25A, 25kA at 415VAC, for all LV standard applications. It offers new features like Everlink technology, DIN rail and plate mounting capability. It embeds new spring type auxiliaries externally visible. ComPacT NSXm is one of the smallest MCCB on the market, 108mm (W) x 137mm (H) x 80mm (D). This is a 4 poles version with an embedded thermal-magnetic trip unit. It ensures compliance with international standards (IEC 60947/CCC/EAC) and marine specifications.
Specifications:
| Main | |
| Range | ComPacT |
| product name | ComPacT NSXm |
| Range of product | ComPacT NSXm |
| Device short name | NSXm 63B |
| Product or component type | Circuit breaker |
| Device application | Distribution |
| Poles description | 4P |
| Protected poles description | 3D |
| Neutral position | Left |
| [In] rated current | 25 A at 40 °C |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| Network type | AC |
| Network frequency | 50/60 Hz |
| Suitability for isolation | Yes conforming to IEC 60947-2 |
| Utilisation category | Category A |
| [Icu] rated ultimate short-circuit breaking capacity | 50 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 |
| 25 kA Icu at 380...415 V AC 50/60 Hz conforming to IEC 60947-2 | |
| 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 | |
| 10 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 | |
| Performance level | B 25 kA 415 V AC |
| Trip unit name | TM-D |
| Trip unit technology | Thermal-magnetic |
| Trip unit protection functions | LI |
| control type | Toggle |
| Circuit breaker mounting mode | Fixed |
| Complementary | |
| [Ui] rated insulation voltage | 800 V AC 50/60 Hz |
| [Uimp] rated impulse withstand voltage | 8 kV |
| [Ics] rated service short-circuit breaking capacity | 50 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 |
| 25 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2 | |
| 20 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 | |
| 10 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2 | |
| Mechanical durability | 20000 cycles |
| Electrical durability | 20000 cycles at 440 V In/2 |
| 10000 cycles at 440 V In | |
| 10000 cycles at 690 V In/2 | |
| 5000 cycles at 690 V In | |
| Power dissipation per pole | 2.8 W |
| Mounting support | Backplate |
| Mounting position | Horizontal and vertical |
| Flat on the back | |
| Upside connection | Front |
| Downside connection | Front |
| Connection terminals | 1 Everlink lug wire size 2.5…95 mm², rigid or stranded aluminium/copper |
| 1 Everlink lug wire size 2.5…70 mm², flexible copper | |
| Connection pitch | 35 mm with spreaders |
| 27 mm without spreaders | |
| 9 mm pitches | 12 module |
| Trip unit rating | 25 A at 40 °C |
| Long-time pick-up adjustment type Ir (thermal protection) | Adjustable |
| [Ir] long-time protection pick-up adjustment range | 0.7...1 x In |
| Long-time protection delay adjustment type tr | Fixed |
| Neutral protection settings | No protection (3D) |
| Instantaneous protection pick-up adjustment type Ii | Fixed |
| [Ii] instantaneous protection pick-up adjustment range | 600 A |
| Earth-leakage protection | Without |
| Number of slots for electrical auxiliaries | 1 slot(s) for auxiliary switch OF |
| 1 slot(s) for alarm switch SD | |
| 1 slot(s) for voltage release MN or MX | |
| Local signalling | Flag (green) for presence of auxiliary contacts |
| Width (W) | 108 mm |
| Height (H) | 137 mm |
| Depth (D) | 80 mm |
| Product weight | 1.42 kg |
| Colour | Grey (RAL 7016) |
| Environment | |
| Standards | EN/IEC 60947 |
| Pollution degree | 3 conforming to IEC 60664-1 |
| IP degree of protection | IP40 conforming to IEC 60529 |
| IK degree of protection | IK07 conforming to IEC 62262 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Relative humidity | 0…95 % |
| Operating altitude | 2000 m without derating |
| 5000 m with derating |
| Weight | 1.420000 |
|---|---|
| Brand | Schneider Electric |
| Model | C11B6TM025L |
| Color | Black |
| Device Application | Distribution |
| Depth [cm] | 8 |
| Width [cm] | 10.8 |
| Height [cm] | 1.37 |
| Range | ComPacT |
| Family | PPCCB |
| Type | Circuit Breaker |
| Poles | 4P |
| [In] Rated Current | 25 A |
| Voltage ~ Frequency | 50-60 Hz |
| IP Degree of Protection | IP40 |
| IK Degree of Protection | IK07 |
