Central I/O module, SpaceLogic, 8 universal inputs, 4 analog voltage outputs
Power consumption in VA: 1 W
Input/output type: Universal input
Number of outputs: 4 analog output
The SpaceLogic UI-8/AO-V-4 is a universal input, 8 channel and analog output, 4 channel I/O expansion module for the SpaceLogic AS-P Server. The universal inputs are ideal for any mix of temperature, pressure, flow, status points and similar point types in a building control system. The analog outputs are capable of supporting analog voltage point types. They support a wide range of devices, such as actuators. The UI-8/AO-V-4 I/O expansion module features 8 universal inputs and 4 analog voltage outputs. Its dimensions are 114 mm (4.5 in.) in height, 90 mm (3.6 in.) in width and 64 mm (2.5 in.) in depth. This I/O module requires a SpaceLogic Central I/O Terminal Base (SXWTBIOW110001).
Specifications:
Main | |
Net weight | 152 g |
Product or component type | I/O module |
Device short name | UI-8/AO-V-4 |
Height | 114 mm |
Flame retardance | UL94V0-5VB |
Width | 90 mm |
Product certifications | ICES-003 |
FCC part 15 class B | |
CE | |
RCM | |
UL | |
ambient air temperature for storage | -20…70 °C |
Depth | 64 mm |
Ambient air temperature for operation | 0…50 °C |
IP degree of protection | IP20 |
Power consumption in W | 1 W |
Input/output type | Universal input |
Relative humidity | 0…95 % non-condensing |
Number of outputs | 4 analog output |
[Us] rated supply voltage | 24 V DC |
Product name | I/O Modules |
Product brand | Schneider Electric |
Range | EcoStruxure Building Operation |
Complementary | |
Electrical connection | Plug-in sub-base |
Control type | Without |
Product compatibility | Continuum |
Johnson Control | |
Balco | |
I/NET | |
Xenta | |
Satchwell | |
Honeywell | |
Switching frequency | 25 Hz |
Discrete input number | 8 |
Mounting support | DIN rail |
Wall | |
Analogue input type | Configurable voltage, current or probe 0...20 mA |
Configurable voltage, current or probe 0...10 V input voltage | |
Configurable voltage, current or probe 20 kOhm connection of probes | |
Configurable voltage, current or probe 10 kOhm connection of probes | |
Configurable voltage, current or probe 2.2 kOhm connection of probes | |
Configurable voltage, current or probe 1.8 kOhm connection of probes | |
Configurable voltage, current or probe 1 kOhm connection of probes | |
Configurable voltage, current or probe 10 kOhm with shunt | |
Local signalling | LED (green/red) for high signal level |
LED (green/red) for low signal level | |
Range compatibility | EcoStruxure Building Operation TB-IO-W1 terminal base |
Standards | UL 864 |
UL 916 | |
FCC CFR47 part 15 | |
Material | ABS + PC |
| Weight | 0.152000 |
|---|---|
| Brand | Schneider Electric |
| Model | SXWUI8V4X10001 |
| Depth [cm] | 6.4 |
| Width [cm] | 9 |
| Height [cm] | 11.4 |
| Range | EcoStruxure Building Operation |
